Specializing in CNC sheet metal stamping parts and machines. If desired, further processing or assembly production.

We have since 2008 been in Sondertorbau worked and finished there also milling, turning, sheet metal and welding parts, which we mount itself. See www.alpgate.eu, enclose the Chamber of Commerce extract.
In cooperation with a partner company, we manufacture for a few years and for external companies.

Our machinery:

Sheet metal working:
Laser system:
- Work area: 3000x1500 mm
- Material thickness:
o steel up to 25 mm
o Stainless steel up to 20 mm
o aluminum up to 12 mm

Autogenschneideanlage:
- Workspace 3000 x 1500 mm
- Material thickness: steel up to 80 mm

press brakes:
- Workspace: 3000mm, 2000kN.

Machining:
- Machining center 5 axis: Working area X 3000, Y 850, Z 800 mm
- Machining center 5 axes: Workspace X 2000, Y 800, Z 800 mm
- Machining center 5 axis: Working area X 762, Y 508, Z 508 mm
- Machining center 3 axis 2x : Working area X 1300, Y 670, Z 625 mm
- Lathe with sub-spindle: Area D max.481 mm, L max. 760mm, Y 104 mm, passage 88mm
- Lathe with sub-spindle: Area D max. 406 mm, L max. 584mm, Y 102 mm, passage 88mm

Welding:
- Welding robot with rotating swivel device
- MIG MAG welding machines
- TIG welders

Others:
- Measuring Machine: Measuring range X 2000, Y800, Z600

Please tell us how to proceed for an application on your site.
thank you

Best regards

We offer from the region 04509 Krostitz / Delitzsch bend the technologies, folding, punching, nibbling and to weld.

The company EURICH & SCHELLER GmbH, based in Bornheim / Rhein-Sieg-Kreis, was founded by Wilhelm Eurich and Alexander Scheller. The focus of the service and product portfolio is the development, design and manufacture of electronics and metal housings. Our own production area enables us to produce prototypes on the basis of a product idea in a very short time. In the field of contract manufacturing, we are happy to support you with our manufacturing capacities.

We are equipped with the most modern CNC machines from Trumph (edging) and DATRON (milling). Riveting, pressing and assembly are also part of our range of services. ESD work tables are available for equipping assemblies.

When it comes to the development of mobile environmental enclosures and EMC protection is also an issue, then you've come to the right place. Perhaps we already have a ready-made housing concept for you in the 19 "or embedded area ?!

Please do not hesitate to contact us!

From the initial sketch through to 3D design to the finished product - with us you get everything from one source! In between are processing steps such as laser cutting, punching, bending, welding, riveting, polishing, powder coating and assembly. With modern equipment and qualified staff we have but the way individual pieces, small series manufacture large quantities according to customer requirements. Through close cooperation with our business partners, we have achieved flexibility, quality and punctuality at the highest level. Our years of experience in the metal industry allows us not only to manufacture your products with diligence and accuracy, but also to find the optimal design solutions and deliver.

Translation by Google Translate

Service staff in the field of laser parts (various metal blanks)

Established in 1978, our family can look back on many years of experience in design and construction of punching and bending tools.

In our workshop, the traditional craft of the tool builder meets the art of our time. State of the art machinery, computer programming systems and the expert knowledge of our staff guarantees the highest precision and persistently convincing quality.

For our high quality standards, we received 1999 AGQS certificate according to DIN 9002 (reg. AGQS-TO-188-99-00).
In a further examination 2003, a new quality management system according to the requirements of DIN EN ISO 9001:2000 was introduced by AUDIT (AUDIT-Reg.-Nr. AGQS-Q-188-R10).

Our customers can rely on the superior service, fast delivery and convincing quality. Wanting to get an idea of the quality of our work! We advise you gladly.


Karl-Heinz Evertz
Marc Evertz

Materials
A demand-sorted material storage provides the conditions for short delivery times, maximum flexibility and punctuality. Also, the materials used, the quality plays a decisive role: For use only high-quality cold-rolled strips reputable, certified mills come. Materials are processed from 0.05 to 10 mm thick and coil widths up to 400 mm.
The range of materials includes the following qualities:
Unalloyed steels according to DIN EN 10139
Hardening steels according to DIN EN 10132-2
Quenched and tempered steels according to DIN EN 10132-3
Spring steels according to DIN EN 10132-4
Stainless steels according to DIN EN 10088-2
Aluminum and wrought aluminum alloys according to DIN EN 485-1 and DIN EN 485-2
Copper and wrought copper alloys according to DIN EN 1652 and DIN EN 13599
Hard paper, pressboard, plastic

Toolmaking
The quality of the tool is one of the most important prerequisites for trouble-free and efficient punching parts production.

The tooling of E. Winkemann manufactures tools with highest precision. The field of tool / construction is equipped among others with the following devices:
2D and 3D CAD systems in the field of tool design
CNC EDM, drilling, milling and jig grinders with CAM connection
The exchange of design data is in IGES or DXF format. For around 6000 are consequential, composite, flexural, and embossing tools or total cuts available.

Stamping technology
The stamping of E. Winkemann is equipped with a powerful machinery, responsive to the diverse areas of use and the materials to be processed.
The machines range from mechanical or hydraulic punching machines and presses to various bending machines:
Hydraulic machinery and punching machines (25 to 500 tons)
Eccentric (10 to 35 tons)
Hydraulic presses (15 to 200 tons)
Punching and bending machines (up to 15)
Stamping machines (up to 200)
Fine blanking machines (up to 700)

Fineblanking / cutting
The fine blanking allows the production of precision parts with smooth cut surfaces and high dimensional accuracy.
Costly rework can be omitted.
Straight-cut percentage up to 100%.
The fine blanking machines with max. 320 tons pressing force can process material thicknesses up to about 7 mm.
In addition, there is also the possibility of products on fine blanking machines with max. To process 700 tons press force.

Flatting
If the required thickness tolerance or flatness can not be achieved by cold rolling with the primary materials with a thickness of 0.8 mm, the parts are ground flat. The result is a thickness tolerance and flatness of ± 0.005 mm. High demands of these parameters are primarily intended for products which are used for example in units and transmissions. Representing this are start-up, passport and shims to call.
Fine grinding
Slices or moldings with a thickness of 0.8 mm and an outer diameter 4.0 mm könnnen be honed for maximum precision requirements with a tolerance of ± 0.001 mm.

Post
For the post-processing of the products are modern, electronically controlled and linked compensation and processing equipment available:
Fully automatic compensation system with process data acquisition and batch documentation
Program-controlled systems for automatic vibratory deburring
Washing and cleaning equipment
Machines and assembly equipment for drilling, tapping, riveting, stamping and assembling.

Surfaces
All parts ...
