About Us

We are happy to introduce you to our company:

The Ackermann CNC-Technik GmbH is an owner-managed, medium-sized company with headquarters based in Southern Freiberg am Neckar. Our production program focuses on turning, milling and drilling parts in medium and large series.

Our years-coordinated and motivated manufacturing team can draw on the latest CNC technology.

Our work and study plans, as well as modern measurement technology, help our quality of thought, to a documentation and reproducibility on operation level.

We are supported which ensures our PPS system for comprehensive transparency of all orders and appointments on a commercial and productive level.

We are proud to be able to the great Swabian automotive manufacturers, as well as their key component suppliers are among our clientele.


Our own products

With the vacuum clamping systems, the dividing heads and the Fasfräsern which continuous
Learn further, we were able to advance in this sector in recent years become the top provider.

o Vacuum Clamping Technology

With our vacuum clamping systems, we have almost all materials under control. This enables components quickly, safely and gently fix. Even thin-walled parts can stretch without distorting. Whether milling, grinding, engraving, printing, lasers or fairs, our vacuum clamping systems have in any case some of the arguments for themselves.
Special solutions are here everyday and can be implemented quickly and economically.
The increased non-magnetic tensile parts (the common materials tend more and more towards aluminum, stainless steel and plastic) have contributed here your part. A sophisticated range of accessories makes from any standard disk, a custom chip solution and provides the customer a high level of investment security.

o vice dividing head

Flexible solutions in the areas of milling, grinding, washing and measuring. Simple, secure and above all accurate clamping and alignment of parts.The clever collet holder which the standard collet types of machine builder uses unique. No additional fixture costs for the customer. Short set-up times by the inclusion in the vise are best argument especially in individual production. A "real" additional axis. (If the state of Bavaria honored as an outstanding invention "Bavarian Innovation Prize 1998")

o bevel cutter

The most rational solution for chamfering tools, our patented bevel cutter. Instead of buying a lot of expensive special cutter (angle), our customers can select the desired bevel angle on the Ackermann-bevel cutter and place in a very short time its required chamfer on the workpiece. The optimal solution for sample, prototype and tooling. A deep range of bevel cutter upgraded here for every eventuality.
All these products are used in own our own manufacturing your use. For this reason, the further development and application consulting customers are practical and sustainable.
This competency package we are today in many industries as by TÜV Süd according to DIN ISO 9001-2008 certified A supplier in ongoing business relationships.

We are processors of plastics, we are working on CNC machines, as well as welding, gluing, hot working ... Our customers are medium-sized Unternemen in the fields of mechanical engineering - Exhibition - Advertising / Marketing and shop.

We manufacture precision turned parts since 1954.
With us ... is milled, drilled, turned, ground ...

We are equipped with machinery that extends from CNC lathes up to highly automated CNC lathes.

In our highly modernized machines are Mazak and Index, Traub, Boley, Gildemeister and Citizen CNC machines as well as manual lathes.

Products:

We manufacture precision turned parts of samples / test parts to small / medium and large series of a diameter of 2 mm to 70 mm and lengths up to 800 mm in the bar area. In the food sector, we finished with a diameter up to 300 mm and a length of up to 250 mm.

Material:

Are processed machining steels and stainless steels as well as the non-ferrous metals copper, brass and aluminum. Plastics: PA6, PA6.6, POM, PDFE and PVC.

Processing methods:

Our modern machinery enables the complete machining of demanding long-and short turned parts as well as milling and grinding work.

Delivery program:

Adapter, axles, bushings, threaded inserts, nozzles, flanges, shafts, fittings, coolant nozzle, hubs, rolling piston, pistons, flanged shafts, spacers, brackets, cranks, plugs, spring plates, pins, rollers, nozzles, washers, valve seats, cone, spool, sockets, spindles, straight pins, cylinder screws, locking screws, soldering nipple, solder lugs, valve plates, valve plug, valve spindles, bolt, rivet, connecting bolts, shield rings, sleeve nuts, ram, sleeves, reducers, locking screws, welding nozzle, solenoid valve housing, double nipple, cover, nut, piston rods

Heat treatment processes and surface coating:

What we can even afford economically upscale, is done in house. More know-how, we supplemented by reliable external partners.

"Function splitting" at the highest level in the interest of power from one source.
We can dadruch all methods of surface hardening, nitriding, nitro-carburizing, Teniferbehandeln, salt bath, sand blasting and the best known methods for surface coating forAs chrome plating, galvanizing, anodizing, chromating and burnishing.

Certified quality:

He who stops being better, you stop at some point to be good at.
Quality management and improvement suggestions, we do not understand as a passing fad but as leitmotifs. We know already that we are with the quality of our precision turned parts in the top group of providers.

But good is not good enough - rest does not fit into our company concept. We define and document that what we do because we want to become even better and more customer-oriented daily.

Our company is certified according to ISO TS 16949:2002.

Adestra metalworking,
flexible modern enterprise, the sheet metal and tube machining, and mechanical machining can offer turning and milling.
We design, produce and assemble according to customer requirements: housing, terminals, machines, machine covers, custom solutions, components and assemblies.

Besides the production of machine-turned parts
sawing, milling, we turn to contract manufacturing
including long-term storage.

The company Adler has in addition to the manufacturing and assembly of mechanical components in the fields of medical technology, laser technology, special engineering and aeronautical engineering mainly due to the machining (milling, drilling, tapping, brushing and grinding, engraving and screen printing and assembly) of custom front panels spezialisiert.Hierbei can be edited in modern Datron milling sizes up to 900x600mm. It changes to both the U-profiles and flat aluminum front panels. The surfaces can be passivated, anodized, anodized / plated and lacquered.


We use aluminum and aluminum alloys, brass, copper and other nonferrous metals, Plexiglas, polycarbonate, PVC, POM, PEEK and Ultem.


The machinery for machining comprises three major processing centers (Chiron FZ22L, Bridgeport VMC 460 and Bridgeport VMC 1000 XP) and 2 Datron milling machine M8, 1-Datron FräsmaschineML1500 and 3 Datron milling machines M2.


For screen printing are 2 semi-automatic machines available.

The company Adolf Brodbeck GmbH + Co. KG was founded in 1929 in Metzingen-Neuhausen at the foot of the Swabian Alb. Today we can look back as middle class family on a successful company history - we have developed into authoritative and powerful manufacturer of special machines and equipment!

Brodbeck- machinery and equipment used for winding, cutting, drying, handling and processing of sleeves of paper or paperboard or for cutting sleeves of plastics. When sleeve manufacturers, printers, film producers and paper mills at home and abroad, our machines are in use. Everywhere they enjoy an excellent reputation, which is due to the reliable and robust design, and the high quality standard and the constant innovation and reliable service.

We use our personal and technical expertise to meet the diverse customer needs and to ensure a cooperative customer care. A future-oriented and experienced management together with the highly qualified staff and employees the important foundation that developed and manufactured in our home machines set in the future in terms of technological requirements and innovation yardsticks.

The family ADO was founded in 2001 and since then performs turning and milling of individual items, as well as to small and medium series by.

The good cooperation with competent partners makes it possible also to offer our customers yet another addition service. These include round and flat grinding, all welding processes, laser and flame cutting and surface treatments and hardening process.

In addition to a flawless, high-quality execution, our company is a fast, economical and flexible to the customer, which is enabled by our lean and efficient disposition.

Due to our PPS system and the MDESystems we are able to individually adjust our production to our customers and respond to particular emergencies. Through this technique, we can guarantee our customers absolute punctuality in every situation.

We guarantee the quality of our work you through competent and motivated employees.Through our clear mission run, the DIN EN ISO 9001:2008, we guarantee quality and punctuality. On request, we conduct a 100% inspection of parts.

Machining
Using the latest CNC technology, we are capable of meeting your requirements, whether single piece or series, to meet the highest quality.

Quality assurance
We guarantee the quality of our work you through competent and motivated employees. Through our clear mission run, the DIN EN ISO 9001:2008, we guarantee quality and punctuality. On request, we conduct a 100% inspection of parts.

Measurement
Quality is our highest demand - measured with the latest 3D coordinate metrology.

Frästeile
max. Length 1020 mm
max. Width 650 mm
max. Height 500 mm

Turned parts
max. Diameter 600 mm
max. Length 800 mm

Flange components
max. Diameter 600.00 mm
max. Length 800.00 mm

Screws, connectors, and gears
max.Diameter 600 mm
max. Length 800 mm

As a specialist for plastic processing, based in Ahaus, we are among the most powerful and flexible providers in NRW and far beyond.

As an established family business, we have, since establishment in 1998, constantly expanding and edit plastics for the most diverse applications, with a very modern machine park.

Conscientiousness, precision and reliability characterize our team of qualified plastic working professionals and designers.

Flexibility, punctuality and defined workflows are the highest of our daily work.

As a customer, you can rely on these properties and be assured that despite all the automation and high utilization, always a high degree of individuality and reliability is offered.

Our range of services includes - from complex single piece up to the large-volume series products - the complete range of innovative plastics.

Our team is always available and accompanies you from development to delivery.
Talk to us!


Production possibilities

At about 2,000 square meters production area we work at the highest technical level of plastic products.

The data provided by you (eg DXF, DWG), and provided drawings will be processed cleanly and efficiently by our trained personnel.

Depending on the product and requirement we use the latest, supported by CAD / CAM, CNC machines.

CNC - milling • 3 Axis
Workspace x • y • z
610 x 510 x 610 mm
760 x 510 x 610 mm
1000 x 610 x 610 mm
2,400 x 500 x 400 mm
3,000 x 1,250 x 600 mm

CNC milling machines • 4 axes
Workspace x • y • z
2,400 x 500 x 400 mm

CNC - lathes
max. Bar passage - Ø 85 mm
max. Turning diameter - 300 mm diameter
max.Distance between centers - Ø 500 mm
Turning with driven tools

Milling machine
max. Length - 6,000 mm

Water jet cutting
max. Size - 3.000 x 1.000 mm
Strength - up to 20 mm

Materials at a glance

Basically, we handle all thermoplastics, thermosets and elastomers.

PP - polypropylene
PA - Polyamide
POM - Acetal
PVC - polyvinyl chloride
PETP - polyethylene terephthalate
PVDF - polyvinylidene fluoride
PTFE - polytetrafluoroethylene
PEEK - polyetheretherketone
HGW - hard tissue
PUR - Polyurethane
