UMI (Uitgeest Mechanische Industrie) is a high-tech machine factory with ISO 9002 certification and space travel approval.

The company specialises in the manufacture of high-quality finished products, their assemblies and the associated components.

Many finished products originate from the development that UMI carries out for its clients.

Rapid prototyping by means of a CAD/CAM coupling is one of the advanced techniques in which UMI is proficient.
UMI is partner and producer to clients in the following sectors: general mechanical engineering, space travel, consumer electronics, medicine, astronomy and the automotive industry

HTT founded in 1997, has been engaged in Deep Hole Drilling technology since her beginning. HTT can supply customer efficient solutions of deep hole drilling in such industries as automotive, defense, aerospace, nuclear, die & mould, pellet mill, etc.
Our drilling range is from hole Ø 1.0 mm to 800 mm, hole length up to 15.000 mm.
With Quality Management Certificate ISO 9001:2000 and CE Certificate, HTT is your reliable partner for Deep Hole Drilling Machines, Job Shop Drilling and Service.

In 1961, Hubert Bulach in Baden-Württemberg Gammertingen the company Hubert Bulach, arts and crafts metal goods. Over the years, the company was restructured to supply work in the stamping and welding area. A consequent expansion was then 1986, the own tool and die making.

Meanwhile, the complete tube processing is possible.

Flexibility, reliability and high quality are the hallmarks of our company in the field of sheet metal and tube machining and tool making.

Punching - Bending - Pull

On several eccentric presses and hydraulic, CNC-controlled punching and stamping press with die cushion, we manufacture parts according to drawings, samples or customer with a press capacity to 200 tons and a clamping area of 1000x1200 mm.

Furthermore there is a controlled press brake for bending sheet metal parts up to 4mm thickness and 2000mm length.

Further processing such as surface treatment, welding, riveting and assembly to the finished part, we like to take over for you.

MIG - MAG & TIG

For precise and high-quality welds, a welding robot is used.

In addition, we have the possibility of producing welds on bends or angles bows with a controlled rotary welding table.

Bolts and spot welding operations are also carried out at us.

Rohrbiegetechnik

After drawing, sample or customer specification, we turn your pipes up to diameter 42x2mm and a length of 4 m on a CNC controlled pipe bending machine.
Further processing measures such as end form, punching or welding are also carried out by us.

Toolmaking

Tool designs in 2-D and 3-D area are created according to customer specifications, parts drawings or information from us.

All popular file formats can be read.
The connection of all machines to the CAD / CAM system allows for flexible and efficient manufacturing of tools.

- Drawing tools
- Follow-up and follow-on composite tools
- Punching tools for inlays
- Bending tools
- Tensioning, welding and testing
- Injection molds
- Foam molds

Wire and die-sinking EDM

We erode for you from item to small series.

Wire EDM
Sinking EDM

HUBERT Erdkamp IND. CNC MANUFACTURING

Erdkamp precision engineering is a service company in the field of milling, drilling and contract manufacturing.

Our Services

* We manufacture precision parts in steel, cast aluminum, plastics and styrofoam.
* Chipping production with CNC milling machines
* Machining size to x = 2000mm, y = 600mm z = 500mm
* According to your demand we will make you an offer in the short term.
* If you want to work with us, we will carry out the contract in the period agreed with you.
* We place great emphasis on high quality, on time and on time delivery of our products.

The tooling was founded in 1906 and currently employs 60 people. Focuses on the areas of tool and equipment, as well as contract manufacturing in the field of machining and EDM.

Our customer base spans virtually all areas of automotive, capital and consumer goods industry and includes many names that are at the forefront of the world market.

Construction
We design our tools in 3D mainly on Catia V5 from IBM. In addition, eligible for 2D and 5-axis machining Tebis and Cadda V4 used. The data is done with dial name or e-mail in the IGES formats 2 - and 3D, VDAFS, CATIA, DXF or DWG.

Toolmaking
* Follow-on composite tools
* Cutting and punching tools
* Bending Tools
* Stamping and pressing tools
* Foil cutting tools
* Foil deep drawing tools

We design and manufacture according to supplied designs presented or patterns, tools up to a size of 1200x4000 mm and a weight of max.25,000 kg.

State of the art production facilities make it possible to edit the design in 3D CNC-controlled production to initial sample inspection reports on 3D measuring machines, virtually any data and drawing documents.

Years of experience and a largely self-trained staff allows us to implement safe production of complex tasks in the situation.

Precise milling and wire EDM in air conditioned rooms give us the opportunity to manufacture cutting tools with an average gap of less than 10 microns.

In series production, we rely on machining centers manufactured by Heller with a pallet changer.
With speeds up to 16,000 min-1 and rapid traverses up to 90m/min and aluminum parts are to be machined economically

Jigs and fixtures
* Welding equipment
* Benders
* Drilling, milling and turning device
* Testers
* Handling Systems

Another mainstay is the manufacture of devices for the mechanical manufacturing, welding machining and measurement and testing tasks.

Certified welders ensure a stable basic structure, annealing furnaces for stress-free post-processing, and milling machines up to 5 axis for precise stop points in space. Modern 3-D coordinate measuring machines also help in free-form surface area to verify the accuracy measure to record and document.

Contract Manufacturing
CNC milling
CNC turning
CNC Surface Grinding
CNC Wire EDM
CNC sinker EDM
Conv machining
Welding
Heat treatment
Measuring and testing

Power spectrum

Toolmaking
Our clients benefit from our years of experience.

Through innovative tool concepts, the foundations for a low-cost production are laid.

Developed and adapted to the process technology of our customers, we manufacture tools and equipment for a process-safe production.
• pressing and hot pressing tools
• stamping tools
• laminating tools
• deep drawing tools
• Carpet-forming and Hinterschäumwerkzeuge
• Forming / composite tools
• Foaming
• Special tools

Mould
Based on over 30 years experience we offer our customers an increasingly sophisticated and cost-effective solutions.

Hullmann manufactures in Germany and France:
• Foaming for molded foams such as seat cushions and backrests
• foam molds for molded parts made of hard foam
• Mehrnutzenschäumwerkzeuge for moldings Together with the equipment manufacturers, we deliver our molds worldwide.

A team of engineers developed a convincing tool concepts for our customers.

Thanks to the simulation of manufacturing processes, we are able to provide our customers with engineered solutions.

The end of the manufacturing process, each mold is paid off in our laboratory to document next to the tightness of the finished part geometry, underlines the high quality of Hullmann.

Model
Models as decision support for designers are one of the first steps in our process chain.

Only models with a vehicle can be considered realistic.

Our machining centers enable us to be able to create complete cars in 1:1 scale. Whether cubing or auxiliary models for tool and mold making, the traditional team of model builders is one of the pillars of Hullmann.

In model manufactured by Hullmann:
• Working models for mold
• Casting models
• Teach (Prüflehrenbau)
• Waterjetschalten


Jigs and fixtures
For the completion of individual process steps are often independent of the core process of working, used functional facilities.
Whether Hochpräzisionsbohrvorrichtungen for aircraft construction or installation and / or Komplettiereinrichtungen for the automotive industry. The necessary devices are realized by the configuration according to customer specification, through to operational handover of Hullmann.

Examples: devices ...
• ... for the assembly and joining of different, belonging together components in the grille assembly.
• ... for the insertion and braces retainers in the vehicle floor carpets
• ... for the production of a component following converting, to produce variants (RL / LL or gasoline / diesel) of a basic component

Punch presses and thrusters
Specially designed for use in conjunction with Hullmann punching and forming a lighter and less expensive pressure transducer was developed.

The hydraulic control of the pressure transducer is designed for safe press control with safety block and monitored valves and follows the latest UV and VBG regulations.The CE marking and the corresponding Declaration of Conformity is self-

The machine base is strong even in the basic version. In addition to a light curtain on the operating side of the pressure transducer and sitema clamping heads for safety and comfort during operation, the control system is constructed on the basis of a PLC SIEMENS S7. It can be completed on request with different visualizations in the add-on package.

HUMMEL AG is a world-renowned manufacturer of cable glands, connectors, heating and plumbing products and customers turned parts with more than 350 employees.

Since its founding in 1948 HUMMEL enforced by entrepreneurial instincts and innovative technology to the markets of the world. Own locations in southern Europe, the Far East and South America are the logical consequence of our international growth. At the headquarters Waldkirch advanced technology of the machinery guarantee precise, flexible and efficient production with the highest quality and service for the customer.

Metal & Plastics Technology

The metals and plastics technology (MK) contains the complete production facilities of HUMMEL AG. Especially the HUMMEL products are manufactured according to ISO 9001:2000 On a production area of over 8,000 m²:

* Cable Glands,
* Circular Connectors,
* Vent valves, ....

These manufacturing facilities also allow for customized solutions. With our advanced machinery and equipment park and the know-how acquired over 60 years of metal and plastic processing, we produce customized special parts for other well-known manufacturers, such as from the Heizkreisverteilerbau, from the electronics and automotive supply industry, building musical instruments and from the Optoelectronics .

HUMMEL underscores not only its own product quality, but also offers the customer nor the HUMMEL quality for its own products.

The MK business currently employs over 120 employees.

The power spectrum of HUMMEL includes:

Materials:
Non-ferrous metals (brass, aluminum, nickel silver, bronze, etc.),
Automatic turning steels, stainless steels
Plastic (injection technology, bar stock)
Zinc die casting

Dimensions:
Multi-spindle ø 5 mm to ø 52mm
Single-spindle ø 8 mm to ø 100mm

Machinery Machining / Injection:
Ring Dreher (material from the ring) ø 0.5 mm - 5mm
CNC single-spindle ø 5mm - 100mm
Multi-spindle cam-controlled ø 5mm - 52mm
Multi-spindle CNC ø 8mm - 52mm
CNC lathe for machining chuck dia 160mm
Machining centers
Zinc die casting
Plastic injection molding machine (clamping force + parts by weight)
Vertical injection molding machine for molding of parts (washers)

Assembly:
complete assembly (Small and medium series)

Coating:
galvanic coating

kvhj,vj,

We founded our firm in 2005 based on our several years of experiences in engineering and in manufacturing practices.
Mainly, we use our experiences in single-purpose machine designing, automated assembling, industrial automation, special machine engineering and 3D modeling, cutting (milling, turning etc.) and welding. It can be a simple tool or a complete production line.
Besides, we undertake the implementation of constructive tasks in different fields of mechanical engineering.
Our costumers are mostly electronic, motor industrial, food industrial companies, multinational companies, for whom we design and produce customized devices according to their special needs.

We made more videos about our works, which summarizes our most successful projects and results in mechanical engineering. You can see these on our website.

In August 2012 we started to implement the ISO 9001:2008 quality management system. Our company operates according to the requirements of the ISO 9001:2015 standard.

The company Hüttinger & Harmful GmbH was founded in 1992. Initially, our services to the maintenance and repair of industrial equipment and machinery related. Gradually expressed by our customers desire expensive original parts inexpensive to manufacture, supply and install. Today we already manufacture complete equipment, containers and machinery, to the planning, calculation and construction. But even single-u. Series production as a supplier for the engineering and produzierenten industry in general.

The second division includes the installation of heating u. Ventilation systems, plumbing and piping in its great variety of embodiments.

Jozef Hargas - HYPERON is a company that can offer complete services in production and sales with refined lines, cable drums and installed cable systems.

Our products are, for example, used in manufacture of machinery for the food industry, equipment, Lifting Equipment, etc..

Our company is located in Nove Mesto nad Vahom, a town in western Slovakia in the heart of Europe. Thus we have the possibility of goods - to deliver quickly from Slovakia in all other European countries and back - without border formalities.

We guarantee short installation work and have workshops and a specialized laboratory.

In mass production harnesses and cables are produced with the assistance of machinery and manufactured in small to medium batch production of cable harnesses by hand.

The conductor cross-sections can in the processing of 0.08 mm ² / AWG28 to 6 mm ² / AWG10 lie.

Our manufacturing facilities and our staff are available to you. Our work area includes the cable assembly, ribbon cable manufacturing, crimping, cable production, stripping, cable harnesses. In addition, you can use our packing services and much more are available.

The company IAV turned parts GmbH is a family from the Sauerland region with a production area of 3'000m ². We have ethabliert us internationally to a major manufacturer and currently serve clients in over 30 countries.

WHAT WE CAN DO:

- Turn (with milling)
- Automatic turning (bar)
- Long-turning
- Shaft
- Machining
- Thread rolling / thread rolling
- Thread whirling
- Upsetting
- Forging
- Burnishing
- Stelliting

For these technologies, we have eg the following products:

Confederation spindles, trapezoidal screws, valve spindles, forged Hammerkofpspindeln, seals with wear-resistant Stellited surface, back seat bolts, threaded rods, nuts, shafts, spacers, Metric thread inch thread, acme screw,

Materials we use such as: 1.4006, 1.4021, 1.4305, 1.4404, Monel, Inconel, Hastelloy, SS410 ASTM A479 AD, ASTM A106

Engineering services - automotive industry (OEMs and suppliers)
Parts are manufactured and Versuchsmusterbau for prototypes (individual productions and mini-series), Machining, Welding metal machining, sheet metal forming, tube machining, quality assurance / fine measuring space, turning, bending, milling, welding

Region of Saxony (09120) Chemnitz

Machined materials are mainly aluminum, aluminum alloy, steel, stainless steel, plastic.

For range of parts including car parts, engine parts, engine components, systems and equipment, test set-ups.
Examples are manufacturing cylinder heads, pistons, crankcase, crankshafts, camshafts and components for mechanical engineering and plant construction.

The IBG Steinicke GmbH, based in Büdingen, specializes in the development and production of high quality sewer cleaning nozzles and milling systems.

The close cooperation with the users has led to a constant development and improvement of our products and technologically advanced solutions. For this reason, we offer not only standard nozzles, but also individual solutions for specific applications.

In addition to the nozzles products offers the IBG Steinicke GmbH and rehabilitation equipment
how the milling robot "HydroCut" which is highlighted by its innovative concept, high user friendliness as well as its attractive price-performance ratio.
The HydroCut milling robot is available in four different versions, which the workspaces
Cover DN 600 - DN 90.

To complete the milling robot series, the IBG also provides complete vehicle conversions
in different variations on. This allows the customer a complete solution
according to his individual needs.

To extend the milling robot series developed IBG Steinicke GmbH the LCCD
with air-driven carriage, the perfect tool for home repair connection.
Its 360 ° rotating guide arm allows cleaning of all side gates.

Construction - sample production - volume production of turned and milled parts
