Materials
A demand-sorted material storage provides the conditions for short delivery times, maximum flexibility and punctuality. Also, the materials used, the quality plays a decisive role: For use only high-quality cold-rolled strips reputable, certified mills come. Materials are processed from 0.05 to 10 mm thick and coil widths up to 400 mm.
The range of materials includes the following qualities:
Unalloyed steels according to DIN EN 10139
Hardening steels according to DIN EN 10132-2
Quenched and tempered steels according to DIN EN 10132-3
Spring steels according to DIN EN 10132-4
Stainless steels according to DIN EN 10088-2
Aluminum and wrought aluminum alloys according to DIN EN 485-1 and DIN EN 485-2
Copper and wrought copper alloys according to DIN EN 1652 and DIN EN 13599
Hard paper, pressboard, plastic

Toolmaking
The quality of the tool is one of the most important prerequisites for trouble-free and efficient punching parts production.

The tooling of E. Winkemann manufactures tools with highest precision. The field of tool / construction is equipped among others with the following devices:
2D and 3D CAD systems in the field of tool design
CNC EDM, drilling, milling and jig grinders with CAM connection
The exchange of design data is in IGES or DXF format. For around 6000 are consequential, composite, flexural, and embossing tools or total cuts available.

Stamping technology
The stamping of E. Winkemann is equipped with a powerful machinery, responsive to the diverse areas of use and the materials to be processed.
The machines range from mechanical or hydraulic punching machines and presses to various bending machines:
Hydraulic machinery and punching machines (25 to 500 tons)
Eccentric (10 to 35 tons)
Hydraulic presses (15 to 200 tons)
Punching and bending machines (up to 15)
Stamping machines (up to 200)
Fine blanking machines (up to 700)

Fineblanking / cutting
The fine blanking allows the production of precision parts with smooth cut surfaces and high dimensional accuracy.
Costly rework can be omitted.
Straight-cut percentage up to 100%.
The fine blanking machines with max. 320 tons pressing force can process material thicknesses up to about 7 mm.
In addition, there is also the possibility of products on fine blanking machines with max. To process 700 tons press force.

Flatting
If the required thickness tolerance or flatness can not be achieved by cold rolling with the primary materials with a thickness of 0.8 mm, the parts are ground flat. The result is a thickness tolerance and flatness of ± 0.005 mm. High demands of these parameters are primarily intended for products which are used for example in units and transmissions. Representing this are start-up, passport and shims to call.
Fine grinding
Slices or moldings with a thickness of 0.8 mm and an outer diameter 4.0 mm könnnen be honed for maximum precision requirements with a tolerance of ± 0.001 mm.

Post
For the post-processing of the products are modern, electronically controlled and linked compensation and processing equipment available:
Fully automatic compensation system with process data acquisition and batch documentation
Program-controlled systems for automatic vibratory deburring
Washing and cleaning equipment
Machines and assembly equipment for drilling, tapping, riveting, stamping and assembling.

Surfaces
All parts ...

Our customers appreciate us for our quick and uncomplicated action.
We do not do without first-class equipment and manufacture on a 5-axis simultaneous milling machine DMU 50 from DMG with high precision and uncompromisingly.

Only quality - and that fast!
We are a small, flexible company and work successfully for:


Accuracy:
Your order demands absolute precision, which we offer you.

Simulation:
You will get a perfect result through precise planning and simulation.

Care:
Thanks to the correct handling of the workpiece, we receive the highest quality.

Investment:
We invest in our technology to offer you the best possible results.

The company Wivo since 1998 manufacturer of metal products.



... Since we manufacture turned parts as individual parts and small series in smaller dimensions, milled parts as individual parts and small series, stamping parts in small and large series exceeding 16 tonnes, aluminum bases and enclosures for special machines, welding parts and welded assemblies, mainly for the medical industry in stainless steel, steel and aluminum.



Our strengths lie among other mainly in the production of bending device, punching device, jig and the associated drive technology to complete special machine.


We offer:

Production of:


- Welding (steel, stainless steel, aluminum) in particularly high precision.

- Profile cutting work

- Punching, including dies and bending mold in many variants.

- Turning, milling, surface grinding (also CNC Machining) single and small series

- Punching tools

- Jig, manufacturing teachings of all kinds

- Special device

- Stands and Worktables of all kinds

- Conveyor

- Special machine

- Other special parts on request

- Glass bead blasting

- Manufacture of vehicle parts for classic cars



other additional work for the Order:


- Development of special parts

- CAD drawings

- Preparation of operating instructions, spare parts catalog, Compliance and other required documents

- Instruction and training of operating personnel

Delivery

The company FDB - wire bending and stamping parts was founded in 1995 in Allersberg.

In the years that have passed, we have been able to expand our company further. In 2003 a move to larger production halls became necessary.

We found this in Hilpoltstein, Industriestr. 18, where we still have our headquarters today.

We currently employ 40 people.
The company is run by the Bode and Frassa families.

We, the FEBU are a medium-sized company with 29 employees, and headquarters in the industrial area of Burbach – Würgendorf, plant road 19, with direct connection to the A45.

The foundation of the company FEBU dates back to 1965.
At that time the father of the current managing director Andreas Fey started with the production of punching, pressing and drawing tools, as well as with the production of windshield washers made of metal, in the rooms of his parents’ house.

Due to the increasing demand, the constantly growing space requirements were initially met with the construction of a 150 m² production and storage hall in Burbach-Holzhausen in 1970. Due to the further steady growth of the company, the production and storage areas were moved to Burbach-Würgendorf in 1988, not least because of the favourable transport connections. Through expansions in recent years, a total of 5,350 m² of production and storage space is currently available.

In the following years the product range was extended in all areas.
Stamping technology

With the founding of the company in 1965, the production of the first stampings for the company’s own windscreen washers and water slides began. In addition to the production of stampings for the company’s own products, other customers were quickly acquired and sales were continuously increased through constant investment in the latest machines. Thus, the most modern automatic punching machines and eccentric presses up to 200t pressure are available. For further processing, we have welding presses, automatic threading machines, as well as stud welding equipment and various special machines. Here a production can take place on tools manufactured by us or provided by you.

Among steel (blank, galvanized + coated) and stainless steel we also process non-ferrous metals.

Injection moulding technology
With the decision of the current managing director Andreas Fey in 1993 to implement the production of plastic injection molded parts for the ice scrapers and windshield washers in house to be able to react faster and more flexibly to customer requests, he laid the foundation for the current 16 machines comprehensive injection molding production. After the purchase of the first injection moulding machine it did not take long until further articles from other areas were added and the first 2-component injection moulding machine was purchased, first for the production of the first own 2-component ice scraper, later also for further customer-specific articles. Gradually, the injection moulding production was expanded and finally, with the takeover of the company Schmidt Kunststofftechnik (founded in 1955) at the Biedenkopf-Eckelshausen location in April 2020, a second location was added.

Toolmaking
The in-house tool shop, with which the then founder of the company Horst Fey laid the foundation stone, is still the pillar of all production areas today. Thanks to our ultra-modern tool shop, we can react quickly and precisely to customer requirements and maintain our tools accordingly. Here we design and manufacture punching and injection moulding tools with a tool length of up to 2,000 mm, as well as fixtures and mountings for various machines.

Cleaning equipment and ice scrapers
The production of cleaning equipment includes the production of metal windscreen washers and water sliders, as well as the production of various plastic windscreen washers and ice scrapers. By investing in the most modern machines and developing our own products and tools, we are still able to produce competitively in this field.

Since its foundation in 1965, FEBU has been able to establish itself throughout Europe. The export, also beyond the European borders, shows positive figures.
Due to a manageable number of employees the company remains flexible and can react quickly to special customer requirements.

Fischer stamping and forming technology GmbH was founded in February 1998 by Ralf Fischer. As a longtime leader of the stamping and forming technology in metal processing Breyell, Mr. Fischer was able to gain experience, which are now incorporated consistently into the company. Versatility and flexibility are our strengths.

On 5 eccentric presses and punching machines perforated strips and stamped parts can be manufactured up to 600 mm width and 400 tons press force. Are processed slit strips in the grades: Warm, Cold, Galvanized, stainless steel and aluminum

Processing, order such as cut, degreasing, galvanizing or cure can also be handled by us.
Alternatively, orders can be processed as a reward business or full business.
Customers here include suppliers to the automotive industry, profiler, shelf farmer, construction and furniture industries etc.

The FLAMMMOTEC GmbH & Co. KG was founded (formerly STAN DRAWING, since 1954) 1993. We manufacture in the works of Berlin and Nauen stamped and drawn parts, primarily for the automotive, white goods and electronics industries, primarily in the United series. Other strengths lie in the field of manufacturing of components. We specialize in die-castings of medium size to large stampings (pressing force of up to 16,000 kN). Our stamping presses and transfer presses have table sizes up to 5200 x 2300 mm. The manufactured parts have up to 13 kg in weight and up to 1 m². In addition, welded assemblies are produced on a modern 6-axis welding robots (1 m³ action space, part weight up to 1000 kg) and spot welding machines.

Production

Our parts range covers all types of forged parts in all grades of material from small parts up to parts of approximately 1 m². For years we have specialized in the field of deformation of aluminum and stainless steel sheets (also in sandwich construction).

In our pressing plant single, progressive or transfer dies are used up to a weight of 25 t. There are automatic punching machine with a printing speed 1000-16000 kN and a table size of up to 5200 x 2300 mm. There are additional single presses with a pressure capacity up to 6300 kN in use. For the production of sandwich parts (especially shielding plates made of stainless steel) is a 8000-kN large-scale press.

On our punching machines are used to coil up to a width of 1200 mm and a plate thickness up to 5 mm, depending on the section that process.

We are predestined for assemblies, ie. For the implementation of welded structures with six-axis welding robots and automatic joining of nuts and bolts In order to achieve an optimization of the work, we have assembly, placement and spot welding machines in use.

By working closely with our partners, we are able to also surface coatings and galvanizing on grafts from powder coatings to cathodic dip coating offer.

Logistics

As a supplier with world-resident customers, we measure the Logistics Management utmost importance. As requested, we deliver just in time and place value on adherence to your requirements in terms of delivery quantity and packaging.

Here we support a modern, always with the latest requirements customized IT technology. Our logistics department handles your incoming EDI, Internet or fax calls immediately and ensures that production, storage and shipping can implement your requirements promptly and respond to your needs.

We work together on request as specified by you or by us carriers commissioned reliable partners and respond quickly and flexibly when difficulties arise.

Toolmaking

Our tool guarantees us a high degree of flexibility for changes and remakes of assemblies to customer specifications.

It is an important partner of our pressing plant because downtime is minimized through him.

Through close contact with our production, the tools are optimized in the short term.

Preventive servicing and maintenance are an important prerequisite for safe production. 20 toolmaker / maintenance have three layers in use.

The company Flüss tooling was founded on 01/05/1908 by Heinrich Flüss.
At this time we dealt with the production of electrical switches, star delta switches and cable lugs, which were made from sheets about tools.
Among other things, the company founder Heinrich Flüss developed roller skates and the company HUDORA that were made then about tools of the company Flüss.
Another task was the production of deformed covers for irons, as well as the manufacture of mechanical parts for wringers. For the sign industry we made high-quality metal signs (Horch, NSU, VW) to the deep embossing process.
In 1958, his son Paul Flüss the company he leads today in the third generation with his son Christian Flüss. Flüss tooling manufactures cutting and punching tools for the production of plastic panels for the automotive, appliance and electrical industries.
Next we finished cutting and punching tools for the paper and plastics industry for the manufacture of suchB. Parking ticket labels, price marking labels, magnetic tickets, billets of all types and package carriers for the pharmaceutical industry (eg OP needles) as well as chip and plastic cards according to ISO.

We manufacture on CNC machines and conventional machine. In eroding for over 30 years, we rely on Agie machines. Our CNC machines are always up to date technical Stand.Im CAD / CAM area, we work with NX8 and creo Modeling (formerly ME10/ME30, CoCreate) Erodierprogramme be created mecanic about the software. In the milling area, we work with Heidenhain (415 and he 530i control)
